CH4 sensor, a latest high precision environmental Wireless loRaWAN sensor is designed for greenhouse and industrial application.
It adopts the LoRaWAN protocol for wireless remote transmission, making it an ideal choice for leakage detection and environmental monitoring.
Model No.:
LW302D-CH4Use:
Accurately detect the concentration of ethylene in the environmentPower Supply:
10-30VDCLoRaWAN Mode:
OTAA Class A/C (Default: Class C)Shell Material:
ABSCertificates:
CE,ROHSCustomized Support:
OEM, ODMWarranty:
1 YearWireless Sensor LoRaWAN CH4 Temperature and Humidity
CH4 Sensor Specification:
|
Power Supply |
5~28VDC |
|
LW302D-CH4 Weight |
120g |
|
Operating Emperature |
-20℃~60℃ |
|
Measuring Principle |
Principle of Non Dispersive Infrared (NDIR) |
|
Measuring Range |
CH4:0~100% LEL |
|
Resolution Ratio |
CH4:1%LEL |
| Temp.and Humi. Sensor |
Temp Range:-40~+80 ℃ |
| Accuracy:±0.3 ℃ | |
|
Humi Range:0~99.9 %RH
|
|
|
Accuracy:±2 %RH
|
|
|
Lifespan
|
> 5 years
|
| Frequency |
CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 |
| Mode | OTAA Class A/C (Default: Class C) |
| Reporting cycle |
External power supply:10min(Default reporting cycle)
|
| Communication Protocol | LoRaWAN, LoRa TDMA Networking |
|
Equipment information (Reference) |
AppEUI:0000000000000001 DevEUI:aaaa202404150001 AppKey:00001111222233334444555566667777 MAC Version: LoRaWAN 1.0.3 |
Packaging:
Single gross weight: 0.600 KG
Single package size: 23X20X5 cm
Application:
The High precision CH4 sensor also widely used for gas monitoring of Chemical production, Ward monitoring, Vegetable greenhouse, Livestock and poultry farms, Tunnel monitoring, Cold chain logistics vehicle, Cold storage monitoring, Biosafety laboratory.
Certifications:
We are best gas sensor manufacturer and exporter in China with more than 10 years. Our CH4 sensor products are certified with of CE, ROHS.
