IoT product and technology solution provider

LoRaWAN Solar Soil PH Sensor

Soil pH sensor is an electronic device used to directly or indirectly measure soil acidity and alkalinity. LoRaWAN solar soil pH sensor is a network that wirelessly transmits data to cloud servers and provides continuous power from solar panels and batteries, enabling long-term, unmanned field work.
  • Model No.:

    LW502S-PH
  • Use:

    Used for soil pH monitoring, equipped with remote solar power supply
  • Power Supply:

    Solar Powered + Li-ion Battery
  • LoRaWAN Mode:

    OTAA Class A/C
  • Shell Material:

    ABS
  • Certificates:

    CE,ROHS
  • Customized Support:

    OEM,ODM
  • Warranty:

    1 Year
  • Product Detail

LoRaWAN Solar Soil PH Sensor


LoRaWAN Solar Soil PH Sensor is an integrated IoT monitoring node that can automatically collect soil pH data, wirelessly transmit the data to cloud servers several kilometers away, and provide power through solar panels for long-term field work. It is essentially an "unmanned data sentinel" deployed in fields, orchards, or any area that requires monitoring of soil environment.

main advantages:
Ultra long distance communication: Overcoming the limitations of traditional wireless technologies such as Wi Fi and Bluetooth, it is very suitable for large-scale and outdoor deployment.
Extremely low power consumption: With solar power supply, it can achieve years of maintenance free operation, significantly reducing labor costs.
Flexible deployment: No need for power grids and communication cables, it can be quickly and cost effectively deployed in any location that requires monitoring.
Powerful network capability: A LoRaWAN gateway can simultaneously receive hundreds or thousands of sensor data, with extremely strong scalability.
Real time data: Users can remotely and almost real-time view soil pH data through mobile apps or computer cloud platforms, and make timely management decisions.


Product Applications:



  1. Precision agriculture: guiding variable rate application of lime and fertilizers, optimizing soil environment, and saving agricultural material costs.

  2. Smart Orchard/Tea Garden: Monitor high-value crops such as blueberries and citrus that are sensitive to pH to ensure optimal growth conditions.

  3. Golf course and garden management: Fine tuned maintenance of lawns to maintain optimal landscape effects

  4. Environmental monitoring and ecological restoration: Long term monitoring of soil quality changes in restoration areas such as mining areas and landfills.

  5. Scientific research: providing long-term and continuous field data for agricultural, meteorological and other scientific research projects.




 LoRaWAN solar soil pH sensor:

Power Supply Solar Powered + Li-ion Battery
LW502S Weight 230g
Operating Emperature -20℃~+60℃
Measuring Range Range: 3-9 pH
Resolution: 0.1
PH Sensor External Dimensions 45*15*123mm
Steel Needle Material Stainless Steel
Sealing Material Black flame retardant epoxy resin
Transmitter Line length Default 2m (other lengths can be customized)
Frequency CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4
Mode OTAA Class A/C
Reporting cycle 30 min (default)
Battery life ≤5 years (Depending on the on-site lighting conditions)
Communication Protocol LoRaWAN
Equipment information(Reference) AppEUI:0000000000000001
DevEUI:aaaa202404150001
AppKey:00001111222233334444555566667777
MAC Version:LoRaWAN 1.0.3


Packaging:

Single gross weight: 1.100 KG

Single package size: 23X21X5cm




Product Description:




Application:


The LoRaWAN Solar Soil PH Sensor is a perfect example of the implementation of IoT technology in agriculture and the environment. It solves the core pain points of traditional monitoring methods in terms of manpower, distance, cost, and sustainability through the innovative integration of sensing, communication, and energy technologies, providing a solid data foundation for achieving digital and intelligent fine management.






Production Process:



factory of water ec sensor manufacturer



Why choose us:


1. Strong R & D: 30+ Senior experts and highly educated personnel formed a R & D team, heavy investment, master a number of core technologies and patents.
2. Professional and effective solutions: for smart environmental protection, agriculture and other fields, to provide customized compound networking solutions.
3. Full range of products: covering the whole industry chain products from data collection to platform services to meet diverse needs.
4. Excellent quality: we have perfect quality control system, strictly quality control each production link, low defective rate.
5. Good service: 7×24 hours fast response, Professional pre-sale, sale, after-sales team support.
