LoRaWAN Water Quality Sensor | Solar Powered, Online Monitoring of Residual Chlorine, Turbidity, and Temperature

The solar residual chlorine(CL) sensor is an outdoor water quality monitoring device that uses solar power to achieve real-time detection and remote data transmission of residual chlorine content. It is suitable for scenarios such as aquaculture and sewage treatment, and has the characteristics of no wiring and low maintenance.
  • Model No.:

    LW104S-YL
  • Use:

    Used for monitoring residual chlorine concentration in water quality
  • Power Supply:

    Solar Powered + Li-ion Battery
  • Measuring Accuracy:

    ±5%FS
  • LoRaWAN Mode:

    OTAA Class A/C
  • Shell Material:

    ABS
  • Certificates:

    CE,ROHS
  • Customized Support:

    OEM,ODM
  • Warranty:

    1 Year
  • Product Detail

Remote Calibration of Solar LoRaWAN Water Quality Residual Chlorine Sensor


The solar residual chlorine sensor is an outdoor water quality monitoring device powered by photovoltaics, which detects the residual chlorine content in water in real time through high-precision electrodes. The device has wireless transmission function and can remotely upload data to the monitoring platform.

This sensor is suitable for scenarios such as aquaculture, drinking water treatment, and sewage treatment. It has the characteristics of easy installation, no wiring, and low maintenance, and is an ideal solution for achieving intelligent water quality management.


Water Quality Solar CL Sensor Specification:


Power Supply Solar Powered + Li-ion Battery
Weight 230g
Working Conditions
Temperature resistance of transmitter components: 0-50 ℃
PH:4-9
Flow rate: 30-60L/h
Measuring Range 0-2mg/L,0-10mg/L,0-20mg/L
Measurement Error ±5%FS
Resolution Ratio
±0.05mg/L
Temperature measurement range
0~60℃,Resolution Ratio:0.1℃
Electrode usage cycle 12 Months
Pressurization 0.6Mpa

Transmitter Line Length

Default 5m (other lengths can be customized)
Frequency CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4
Mode OTAA Class A/C
Reporting cycle 30min(Default)
Communication Protocol LoRaWAN
Equipment information
(Reference)
AppEUI: 0000000000000001
DevEUI: aaaa202404150001
AppKey: 00001111222233334444555566667777
MAC Version: LoRaWAN 1.0.3


Packaging:

Single gross weight: 1.200 KG

Single package size: 37X26X5cm


Product Description:




Customer on-site examples:




Application:


Solar residual chlorine(CL) sensors are widely used in outdoor scenarios such as aquaculture, drinking water disinfection, and sewage treatment to monitor residual chlorine concentration in real-time and ensure water quality safety. With solar power supply and wireless transmission characteristics, it is particularly suitable for long-term monitoring needs in remote areas and environments without mains power.

applications of versatile Residual Chlorine Sensor



Certifications


We are best solar water quality residual chlorine(CL) sensor manufacturer and exporter in China with more than 10 years. Our solar water residual chlorine(CL) sensor products are certified  with of CE, ROHS.



Production Process:



factory of water ec sensor manufacturer



Why choose us:


1. Strong R & D: 30+ Senior experts and highly educated personnel formed a R & D team, heavy investment, master a number of core technologies and patents.
2. Professional and effective solutions: for smart environmental protection, agriculture and other fields, to provide customized compound networking solutions.
3. Full range of products: covering the whole industry chain products from data collection to platform services to meet diverse needs.
4. Excellent quality: we have perfect quality control system, strictly quality control each production link, low defective rate.
5. Good service: 7×24 hours fast response, Professional pre-sale, sale, after-sales team support.
